    PID Control S310 105kW Vacuum Atmosphere Electric Heat Treat Furnace

    Ask Lasest Price
    Brand Name : WONDERY
    Model Number : RJ2-105-11
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 200SETS PER YEAR
    Delivery Time : 30-40 DAYS
    • Product Details
    • Company Profile

    PID Control S310 105kW Vacuum Atmosphere Electric Heat Treat Furnace

    Pit Type Vacuum Protective Atmosphere Furnace For Hardening Damascus Knives


    1. Application of electric heat treat furnace

    The pit type vacuum atmosphere furnace is used for heat treatment and heating of non ferrous metal parts and stainless steel knives. It is also used for heat treatment of other parts.

    pt type furnace/steel wire annealing furnace/ electric heat treatment furnace


    2. Equipment description and technical proposal

    The RJ2-105-11 pit type vacuum protective atmosphere furnace is comprised of furnace body, furnac lining, heating elements, muffle tank, protective atmosphere supply device and control system.


    2.1 furnace body

    The shell of the furnace body is welded by section steel and steel plate. The thickness of 4mm±0.5 steel plate is rolled into a round barrel shape. The furnace bottom is made of channel steel, and the thickness of the bottom plate is 6mm±0.5.


    2.2 lining

    The furnace lining is all fiber structure which are fixed to the furnace body by stainless steel fixtures. The total lining thickness is 325mm, including 300mm pre-compressed fiber block and 25mm back lining insulation cotton.


    2.3 heating elements

    The furnace employs quality 0Cr27AL7Mo2 high temperature alloy belts as heating elements. The heating element is retained to the furnace wall through porcelain nails.


    2.4 muffle tank

    The muffle tank is made from 10mm 310S stainless steel plate. It is placed in the furnace hearth. The cover and bottom of the furnace body are both pressed into shape.


    2.5 protective supply device

    The furnace cover is equipped with air inlet (including manual valve), air outlet (including manual valve), pressure indicator in the furnace, rings, etc.


    2.6 furnace cover up and down device

    The furnace cover is up and down by electric screw.


    2.7 temperature control system

    Temperature control: the furnace adopts Changzhou Huibang intelligent temperature controller to control the temperature which has self-tuning function to calculate the ideal PID parameter and achieve temperature stability.


    3. Main Parameters of electric heat treat furnace

    No.NameTechnical Parameter
    1Rated heating power105KW(1-100% adjustable)
    2Power supply380V,3phase,50HZ
    3Rated temperature

    Max temperature:1150℃

    Normal working temperature: 1050-1070℃

    4Temperature control zone1 zone + 1 point temperature measurement
    5Furnace cover liftingLifting by screw
    6Muffle tank effective working sizeØ1200×1200mm (diameter × height)
    7Temperature uniformity±10℃
    8Temperature control accuracy±2℃
    9Empty furnace heating up time≤1.5hours
    10Empty furnace power consumption≤18KW
    11Temperature control methodPID control, Intelligent temperature controllor, over temperautre alarm and timing function
    12Muffle tank material310S stainless steel, 10mm thickness
    13Furnace lining

    refractory fiber for wall and cover;

    refractory bricks for bottom

    14Heating elements0Cr27AL7Mo2
    15Protective atmosphere

    high purity nitrogen

    pit type furnace/steel wire annealing furnace/ electric heat treatment furnace
