Vertical Expander HVAC Equipment for Household Air Conditioners
1. Main Features
1.1 The vertical tube expanding machine adopts the two guide pillar
design with stronger main frame.
1.2 The HVAC machine uses the servo motor to control the expansion
of
the pipe inside with high accuracy and good quality.
1.3 The vertical expander machine is designed with the separate
which is
easy and quick for maintenance.
1.4 The vertical expander is set with the high quality imported
brand touch
screen. It is convenient and effcient for the operation.
1.5 This heat exchanger tube expander can complete the expansion
and flaring process automatically.
1.6 The vertical expanding machine is equipped with quality
hydraulic
Yuken brand valve. The oil temperature is of automatic control.
2.Technical Parameters
| Item | Specification |
| Model | WDLV-850 | WDLV-1200 | WDLV-1600 |
WDLV-2000 | WDLV-2500 |
WDLV-3000
|
| Max Length of tube expander (mm) | 200-850 | 200-1200 | 200-1600 | 250-2000 | 300-2500 | 300-3000
|
| Pipe Diameter (mm) | Ф5,Ф7,Ф7.94,Ф9.52and other diameter
|
| Wall Thickness mm | 0.25-0.81
|
| Pitch-row X Pitch mm | According to customer’s drawing
|
| Max row number of Tube Expander | 8 |
| Max Hole Number of hole sineach expander | 60 |
| Fin Hole Diameter | Customized
|
| Fin holes arrangement | Plover or Parallel, customized
|
| Diameter of the tube expanding cylinder | Ф150,Ф180,Ф200,Ф220
|
| Total Power KW | 7.5,15,22
|
| Hydraulic Pressure | ≤14Mpa
|
| Expanding Speed | About 5.5mm/min
|
3. Company Introduction
Wondery enjoys a very good reputation and credit in related fields.
We have developed high
quality progressive fin dies with long life and high quality. We
have a professional R&D team,
imported high quality machining center, wiring cutting machines,
drilling machines,etc. We can
control the overall quality of the HVAC equipment and fin dies from
design to manufacture,
and the lifelong after sales service. We have more than 20 years
experience in this HVAC
equipment fiedl. We are a professional supplier of full HVAC
equipment production line such
as fin press machine, progressive fin die, vertical tube expanding
machine, hairpin bender,
return bending machine, heat exchanger bending machine, etc.
