170kg/H Continuous Extrusion Radiator Separator Machine 300mm Diameter

Ask Lasest Price
Brand Name :	WONDERY
Model Number :	HSPC300
Certification :	CE
Price :	Negotiable
Supply Ability :	100 Set/Sets per Year
Delivery Time :	90 Days

Add to Cart

Product Details
Company Profile

170kg/H Continuous Extrusion Radiator Separator Machine 300mm Diameter

Continuous Extrusion Machinery Making Machine for Brazing Radiators

1. Brief Descriptions of Machinery

The revolving extrusion wheel is driven by a motor, and it guides the feedstock to enter the wheel groove. The feedstock is dragged into the chamber by the friction between the wheel groove and feedstock. The friction generates high temperature and heavy pressure, under the high temperate and pressure, the metal is formed into aluminum tube through a die.

Centered around the Continuous Extrusion Machine, the line is equipped with the straightener for aluminum rod, cooling systems, length counter, take-up stand and other auxiliary equipments based on the actual requirement.

Production flow: Al Feedstock Pay-off → Straightener→Ultrasonic Cleaning→ Continuous Extrusion → Product Cooling → Blow Dry →Dancer →Take-up.

2. Main Technical Parameters

1.Main Machine

Wheel Diameter:	300mm
Drive Power:	132kW
Rated Rotation Speed:	20rpm

2.Feed stock

Rod Diameter for Aluminum Round Tube	9.5mm
Diameter Tolerance	±0.2mm
Material: Clean Continuous Cast and Rolling Aluminum Rod

3. Product

Diameter of Aluminum Round Tube	5~19mm
Minimum Thickness of Round Tube	0.6mm
Maximum Width of Aluminum Multi-void Tube	6~40mm
Minimum Thickness of Multi-void Tube	0.35mm
Average Output (9.5mm aluminum feedstock)	170kg/h
Flash level: (depending on section area)	﹤2%

4. Plant Requirement for one set

Power Supply	AC380V, 3 Phase, 50 Hz, 200KVA
Compression Air	0.6MPa, 5.0m³/min
Loop Cooling Water	>0.5MPa, 30m³/h
Space (L×W×H)	42m ×10m ×6m

3. Hydraulic, Lubricate and Electric Control system

The extrusion machine operates with separated high hydraulic system to clamp the shoe in place by hydraulic cylinders. Separated lubricant system ensures the bearings are adequately lubricated and correct operating statuses are maintained. The main hydraulic component is Yuken product (REXORTH standard component).

Hydraulic oil: ISOVG46 Pump: 3.0kW

Lubrication oil: ISOVG220-320 Pump: 1.1kW+1.5kW

The electrical system adopts Siemens PLC controller, ABB DC Driver and all major components are products of ABB™ Electricity, which ensure the reliability of control system. Voltage specialize for the customer: AC 380V 50Hz / 3 phase.

The production line is controlled by an industrial computer system mounted in the console. Highly specialized control software communicates with the PLC, Control and monitor tasks are automatically done by the PLC.

A graphic operation terminal environment with windows GUI to provide the following features:

· LCD screen control panel of dynamic systems.

· Measurement and recording of operating parameters such as temperatures, speeds, machine load etc.

· Tabular display of primary, secondary and all control parameters.

· Recording of real time product line status.

· Alarms. Fault location indicate and automatic solution guide.

4. Company Info

Wuxi Wondery Trading Co., Ltd is a comprehensive fin radiator making machine supplier. Our company

supplies the following machines: aluminum radiator fin machine, aluminum radiator core builder machine, aluminum

radiator plastic tank clinching machine, aluminum radiator brazing furnace, aluminum radiator leak testing machine,

radiator header plate mold, radiator side plate mold, plastic tank die, etc.
